| Part Number | DV430FHB-R00 |
| Mark | BOE |
| Gréisst | 43 |
| Applikatioun | Digital Signage |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | DV430FHB-R00 |
| Panel Gréisst | 43" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1920(RGB)×1080, FHD, 51PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 940.896(W)×529.254(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 949.5(W)×541.75(H) ×1.4(D) mm |
| Uewerfläch | Antiglare (Haze 1%), Hard coating (3H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Glas Déift | 0.50+0.50 mm |
| transmissivitéit | 6.0% (Typ.) |
| weisen Faarwen | 16.7M |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COFBuilt-in 6 source chips |
| Panel Gewiicht | 1.51Kgs (Typ.) |
| Applikatioun | Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
