| Part Number | DV212FBB-N10 |
| Mark | BOE |
| Gréisst | 21.2 |
| Applikatioun | Digital Signage Stre |
| Opléisung | 1920×360 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | DV212FBB-N10 |
| Panel Gréisst | 21.2" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1920(RGB)×360, 92PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 529.416(W)×99.265(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 537.216(W)×109.6(H) mm |
| Uewerfläch | Antiglare (Haze 25%) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | HADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Glas Déift | - |
| transmissivitéit | 4.8% (Typ.)(with Polarizer) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COF Built-in 6 source + 1 gate chips |
| Panel Gewiicht | 200g (Typ.) |
| Applikatioun | Digital Signage Stretched Bar LCD |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
