| Part Number | DMF-50174 |
| Mark | OPTREX |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | STN-LCD, LCM |
| Hellegkeet | |
| CR | |
| Faarwen | Monochrome |
| Géigeliicht | CCFL |
| Interface | Parallel |
| Mark | OPTREX |
| Modell | DMF-50174 |
| diagonal Gréisst | 5.7 inch |
| Typ | STN-LCD, LCM |
| Pixel Format | 320×240 [QVGA] 70PPI |
| Configuratioun | Rectangle |
| aktiv Beräich | 115.17(H)×86.37(V) mm |
| kontur dim. | 174(H)×112(V) ×14(D) mm |
| bezel Beräich | 122.0(H)×92.0(V) mm |
| Behandlung | - |
| Vue Richtung | - |
| Äntwert Zäit | - |
| Vue Wénkel | - |
| Betribssystemer Modus | STN |
| Ënnerstëtzung Faarf | Monochrome |
| Liichtquell | CCFL , W/O Driver |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 70Hz |
| Touch Panel | Without |
| Interface Typ | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| Stroumversuergung | 5.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
