| Part Number | CM546B2-001 |
| Mark | CSOT |
| Gréisst | 5.5 |
| Applikatioun | Mobile Phone |
| Opléisung | 1080×1920 |
| Zesummesetzung | LTPS TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | |
| Panel Mark | CSOT |
| Panel Modell | CM546B2-001 |
| Panel Gréisst | 5.5" |
| Panel Typ | LTPS TFT-LCD, CELL |
| Resolutioun | 1080(RGB)×1920, FHD, 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 68.04(W)×120.96(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 69.44(W)×126.81(H) ×0.45(D) mm |
| Uewerfläch | With Polarizer |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Display Modus | FFS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Glas Déift | 0.15+0.15 mm |
| transmissivitéit | 4.69% (Typ.)(with APCF) |
| weisen Faarwen | 16.7M 80% NTSC |
| Lampe Typ | No B/L |
| Frequenz | - |
| Touchscreens | In-Cell Touch |
| Chauffeur ic | COG Built-in TD4310 |
| Panel Gewiicht | TBD |
| Applikatioun | Mobile Phone |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
