| Part Number | CLAA123PA02CW |
| Mark | CPT |
| Gréisst | 12.3 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1440×540 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | CPT |
| Modell | CLAA123PA02CW |
| diagonal Gréisst | 12.3 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1440(RGB)×540 125PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 291.6(H)×109.35(V) mm |
| kontur dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| bezel Beräich | 294.8(H)×112.4(V) mm |
| Behandlung | Antiglare (Haze 25%) |
| luminance | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 60/60/50/60 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Liichtquell | WLED [8S3P] , 30K hours , W/O Driver |
| Gewiicht | 510g (Typ.) |
| entworf fir | Industrial Outdoor High Brightness Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| CLAA121UA01CW | CPT | 12.1 | 1600×900 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
