| Part Number | CLAA101WK07 XN |
| Mark | CPT |
| Gréisst | 10.1 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | CPT |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1280(RGB)×720 [WXGA] 144PPI |
| aktiv Beräich | 224.64(H)×126.36(V) mm |
| bezel Beräich | 227.64(H)×129.36(V) mm |
| luminance | 600 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.7M 70% NTSC |
| Gewiicht | 430g (Typ.) |
| Frame Taux | 60Hz |
| Modell | CLAA101WK07 XN |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 238.8(H)×148.05(V) ×8.7(D) mm |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | HFFS, Normally Black, Transmissive |
| Liichtquell | WLED [6S5P] , 30K hours , W/O Driver |
| entworf fir | Automotive Display |
| Touch Panel | Without |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
