| Part Number | CLAA101WK06 XN |
| Mark | CPT |
| Gréisst | 10.1 |
| Applikatioun | Automotive Display |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 6S5P |
| Interface | LVDS |
| Panel Mark | CPT |
| Panel Modell | CLAA101WK06 XN |
| Panel Gréisst | 10.1" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1280(RGB)×720, WXGA, 144PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 224.64(W)×126.36(H) mm |
| bezel Ouverture | 227.64(W)×129.36(H) mm |
| Kontur Gréisst | 238.8(W)×148.05(H) ×8.7(D) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | HFFS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K/16.7M 70% NTSC |
| Lampe Typ | 6S5P WLED , 30K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 430g (Typ.) |
| Applikatioun | Automotive Display |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| Input Volt | 3.3/12.4/24.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
