| Part Number | CC500PV6D |
| Mark | PANDA |
| Gréisst | 50 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | Oxide TFT-LCD, CELL |
| Hellegkeet | |
| CR | 6000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | USI-T |
| Panel Mark | PANDA |
| Panel Modell | CC500PV6D |
| Panel Gréisst | 50" |
| Panel Typ | Oxide TFT-LCD, CELL |
| Resolutioun | 3840(RGB)×2160, UHD, 89PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 1095.8(W)×616.41(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 1105.84(W)×627.91(H) ×1.37(D) mm |
| Uewerfläch | Antiglare (Haze 2.3%), Hard coating (3H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 6000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | UV2A, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| Glas Déift | 0.50+0.50 mm |
| transmissivitéit | 5.0% (Typ.)(with Polarizer) |
| weisen Faarwen | 1.07B 70% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COF Built-in 12 source chips |
| Panel Gewiicht | 2.15Kgs (Typ.) |
| Applikatioun | TV Sets |
| Signal Interface | USI-T , 96 pins Connector |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
