| Part Number | C123HAN02.5 |
| Mark | AUO |
| Gréisst | 12.3 |
| Applikatioun | Automotive Display |
| Opléisung | 1920×720 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S4P WLED , 10K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Modell Numm | C123HAN02.5 |
| Écran Gréisst | 12.3 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×720 167PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 292.032 × 109.512 (H×V) |
| Kontur (mm) | 310.75 × 129.86 × 16.23 (H×V×D) |
| Bezel Beräich (mm) | 293.94 × 111.42 (H×V) |
| Behandlung | Antiglare |
| luminance | 600 cd/m² (Min.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 15/45 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M 75% NTSC |
| mass | 570±57g |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
