| Part Number | C100HAT01.0 |
| Mark | AUO |
| Gréisst | 10.0 |
| Applikatioun | Automotive Display |
| Opléisung | 1560×700 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Modell Numm | C100HAT01.0 |
| Écran Gréisst | 10.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1560(RGB)×700 171PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 231.66 × 103.95 (H×V) |
| Kontur (mm) | 259.36 × 131.32 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare, Antireflection |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 30 (Max.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M |
| mass | 375±38g |
| benotzt fir | Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| ELT256.120.90 | Lumineq | 10.0 | 256×120 |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HSD100PXN1-A00-C11 | HannStar | 10.0 | 1024×768 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| PM100WX2 | E Ink | 10.0 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
| SVA101WV1(01TA)(A) | SVA-NEC | 10.0 | 1024×576 |
| TM100SV-A01-01 | SANYO | 10.0 | 800×600 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
