| Part Number | C084XAN01.0 |
| Mark | AUO |
| Gréisst | 8.4 |
| Applikatioun | Automotive Display |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 8.4 inch |
| Pixel Zuel | 1024(RGB)×768 (XGA) 152PPI |
| aktiv Beräich (mm) | 170.496 × 127.872 (H×V) |
| luminance | - |
| Vue Wénkel | - |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (1 ch, 8-bit) , 40 pins Connector |
| max. Bewäertungen | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| Modell Numm | C084XAN01.0 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | - |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Äntwert | 30 (Max.)(Tr+Td) ms |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| benotzt fir | Automotive Display |
| touchscreen | Without |
