| Part Number | C042FAN01.8 |
| Mark | AUO |
| Gréisst | 4.2 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 480×272 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | 3S2P WLED , 10K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Modell Numm | C042FAN01.8 |
| Écran Gréisst | 4.2 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×272 (WQVGA) 131PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 92.88 × 52.632 (H×V) |
| Kontur (mm) | 102.8 × 68.52 × 20 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare |
| luminance | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| Äntwert | 13/14 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| Faarfdéift | 262K 71% NTSC |
| mass | 89.8g (Typ.) |
| benotzt fir | Outdoor High Brightness Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
