| Part Number | BB050HDG-TC1-6D00 |
| Mark | BOE |
| Gréisst | 5.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 720×1280 |
| Zesummesetzung | AM-OLED, OLED |
| Hellegkeet | |
| CR | 17000:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Modell | BB050HDG-TC1-6D00 |
| Panel Gréisst | 5.0" |
| Panel Typ | AM-OLED, OLED |
| Resolutioun | 720(RGB)×1280, WXGA, 295PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 61.92(W)×110.08(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 64.12(W)×116.72(H) mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 17000:1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Min.) |
| Display Modus | OLED |
| beschte Vue op | Symmetry |
| Äntwert Zäit | - |
| weisen Faarwen | 16.7M 101% NTSC |
| Lampe Typ | self , 10K hours |
| Frequenz | 60Hz |
| Touchscreens | On-Cell Touch |
| Chauffeur ic | COG Built-in RM67120 |
| Panel Gewiicht | TBD |
| Applikatioun | Mobile Phone |
| Signal Interface | MIPI (4 data lanes) |
| Input Volt | 2.8/1.8/6.0/4.6/-3.4V (Typ.)(VCI/VDDIO/AVDD/ELVDD/ELVSS) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
