| Part Number | B154EW02 V0 HW3A |
| Mark | AUO |
| Gréisst | 15.4 |
| Applikatioun | Laptop |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | 1 pcs CCFL , 10K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Modell Numm | B154EW02 V0 HW3A 1 Compatible |
| Écran Gréisst | 15.4 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1280(RGB)×800 (WXGA) 98PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 331.2 × 207 (H×V) |
| Kontur (mm) | - |
| Bezel Beräich (mm) | 335.35 × 211.05 (H×V) |
| Behandlung | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| luminance | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 400 : 1 (Typ.) (TM) |
| Vue Wénkel | 45/45/15/35 (Typ.)(CR≥10) |
| Äntwert | 4/12 (Typ.)(Tr/Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K 45% NTSC |
| kontur Form | Wedge (PCBA Bent, T≥5.2mm) |
| benotzt fir | Laptop |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (1 ch, 6-bit) , 30 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B154EW02 V0 | AUO | 15.4 | 1280×800 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| B154EW02 V2 | AUO | 15.4 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW02 V6 | AUO | 15.4 | 1280×800 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| LTN154U1-L02 | Samsung | 15.4 | 1920×1200 |
| LTN154X3-L09-0 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L09-G | Samsung | 15.4 | 1280×800 |
