| Part Number | B133HAN05.2 |
| Mark | AUO |
| Gréisst | 13.3 |
| Applikatioun | Laptop |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM, LTPS TFT-LCD |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Fabrikant beschwéiert | AUO |
| Modell Numm | B133HAN05.2 (AUO522D) |
| Écran Gréisst | 13.3 inch |
| Écran Typ | LCM, LTPS TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 166PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 293.76 × 165.24 (H×V) |
| Kontur (mm) | 299.46 × 176.98 × 4 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Glare (Haze 0%) |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 30 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M 72% NTSC |
| kontur Form | Slim (PCBA Bent, T≤3.0mm) |
| benotzt fir | Laptop |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | eDP (2 Lanes) , eDP1.4 , Connector 30 pins |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133HAN03.0 | AUO | 13.3 | 1920×1080 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| LQ133K1LA4A | SHARP | 13.3 | 1280×800 |
| LT133X8-122 | Samsung | 13.3 | 1024×768 |
| LTN133AT14-001 | Samsung | 13.3 | 1280×800 |
| N133HSG-WJ1 | Innolux | 13.3 | 1920×1080 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
