| Part Number | B116XAB01.4 |
| Mark | AUO |
| Gréisst | 11.6 |
| Applikatioun | Laptop |
| Opléisung | 1366×768 |
| Zesummesetzung | Assembly , a-Si TF |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , 15K hours , With LED Driver |
| Interface | eDP |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 11.6 inch |
| Pixel Zuel | 1366(RGB)×768 (WXGA) 135PPI |
| aktiv Beräich (mm) | 256.125 × 144 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 235 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 262K 50% NTSC |
| kontur Form | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | B116XAB01.4 (AUO145C) |
| Écran Typ | Assembly , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 284.1 × 185 × 4.05 (H×V×D) |
| Behandlung | Glare (Haze 0%), Hard coating (7H) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Äntwert | 27 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | - |
| benotzt fir | Laptop |
| touchscreen | On-Cell Touch |
