| Part Number | B116XAB01.3 |
| Mark | AUO |
| Gréisst | 11.6 |
| Applikatioun | Laptop |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, Assemb |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | AUO |
| Modell | B116XAB01.3 (AUO288C) |
| diagonal Gréisst | 11.6 inch |
| Typ | a-Si TFT-LCD, Assembly |
| Pixel Format | 1366(RGB)×768 [WXGA] 135PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 256.125(H)×144(V) mm |
| kontur dim. | 284.85(H)×189.84(V) ×4.2(D) mm |
| bezel Beräich | - |
| Behandlung | Glare (Haze 0%), Hard coating (7H) |
| luminance | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 27 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | 16.7M 50% NTSC |
| Liichtquell | WLED , 15K hours , With LED Driver |
| Form Stil | - |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | On-Cell Touch |
| Interface Typ | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
