| Part Number | B080XAT01.1 |
| Mark | AUO |
| Gréisst | 7.9 |
| Applikatioun | PAD |
| Opléisung | 768×1024 |
| Zesummesetzung | Assembly |
| Hellegkeet | 230 |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | AUO |
| Panel Modell | B080XAT01.1 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Panel Gréisst | 7.9 inch |
| Resolutioun | 768(RGB)×1024 , XGA |
| aktiv Beräich | 119.808×159.744 mm |
| skizzéieren | 142×205×6.1 mm |
| Uewerfläch | |
| Hellegkeet | 230 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | MIPI (4 data lanes), 35 pins |
| Input Volt | 3.7V (Typ.) |
| Applikatioun | PAD |
| B080UAN01.4 | AUO | 8.0 | 1200×1920 |
| BP070WX6-400 | BOE | 7.0 | 800×1280 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQA | LG Display | 9.7 | 1024×768 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
