| Part Number | AM480272H3TMQW-TW1H |
| Mark | AMPIRE |
| Gréisst | 4.3 |
| Applikatioun | Industrial |
| Opléisung | 480×272 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 250:1 |
| Faarwen | 65K/262K |
| Géigeliicht | WLED |
| Interface | 8/9/16/18-bit |
| Mark | AMPIRE |
| Modell | AM480272H3TMQW-TW1H |
| diagonal Gréisst | 4.3 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 128PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 95.04(H)×53.856(V) mm |
| kontur dim. | 105.5(H)×67.2(V) ×7.91(D) mm |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 15/35 (Typ.)(Tr/Td) |
| Vue Wénkel | 70/70/35/55 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 65K/262K 52% NTSC |
| Liichtquell | WLED [7S1P] , 15K hours , W/O Driver |
| Gewiicht | TBD |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | 4-wire Resistive Touch |
| Interface Typ | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
