| Part Number | AM-800600MGTMQW-02H |
| Mark | AMPIRE |
| Gréisst | 8.4 |
| Applikatioun | Industrial |
| Opléisung | 800×600 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 12S4P |
| Interface | LVDS |
| Panel Mark | AMPIRE |
| Panel Modell | AM-800600MGTMQW-02H |
| Panel Gréisst | 8.4" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×600, SVGA, 119PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 170.4(W)×127.8(H) mm |
| bezel Ouverture | 174.15(W)×131.2(H) mm |
| Kontur Gréisst | 203(W)×145.5(H) ×11.7(D) mm |
| Uewerfläch | - |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Vue Wénkel | 75/75/60/70 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M |
| Lampe Typ | 12S4P WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | TBD |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
