| Part Number | AM-640480V2TZQW-TA7H |
| Mark | AMPIRE |
| Gréisst | 5.7 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 640×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 262K |
| Géigeliicht | 4S7P |
| Interface | LVDS |
| Panel Mark | AMPIRE |
| Panel Modell | AM-640480V2TZQW-TA7H |
| Panel Gréisst | 5.7" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 640(RGB)×480, VGA, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 115.2(W)×86.4(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 127(W)×98.43(H) ×10.88(D) mm |
| Uewerfläch | - |
| Hellegkeet | 850 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 60% NTSC |
| Lampe Typ | 4S7P WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | PCAP |
| Panel Gewiicht | - |
| Applikatioun | Industrial Outdoor High Brightness |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
