| Part Number | AM-640480G2TNQW-T08H |
| Mark | AMPIRE |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 640×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 250:1 |
| Faarwen | 262K |
| Géigeliicht | WLED , 20K hours , With LED Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | AMPIRE |
| Modell Numm | AM-640480G2TNQW-T08H |
| Écran Gréisst | 5.7 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 640(RGB)×480 (VGA) 141PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 115.2 × 86.4 (H×V) |
| Kontur (mm) | 127 × 98.43 × 10.2 (H×V×D) |
| Bezel Beräich (mm) | 118.0 × 89.2 (H×V) |
| Behandlung | - |
| luminance | 200 cd/m² (Typ.) |
| Kontrast Verhältnis | 250 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/50/50 (Typ.)(CR≥10) |
| Äntwert | 50 (Typ.)(Tr+Td) ms |
| gutt Vue op | 12 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K 50% NTSC |
| mass | - |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| Signal Typ | Parallel RGB (1 ch, 6-bit) , Connector 40 pins |
| Spannungsversuergung | 3.3/5.0V (Typ.)(VCC/VDD) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
