| Part Number | AM-640480G2TNQW-A0H |
| Mark | AMPIRE |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 640×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 250:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AMPIRE |
| Modell | AM-640480G2TNQW-A0H |
| diagonal Gréisst | 5.7 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 640(RGB)×480 [VGA] 141PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 115.2(H)×86.4(V) mm |
| kontur dim. | 127(H)×98.43(V) ×7.8(D) mm |
| bezel Beräich | 118.0(H)×89.2(V) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) (TM) |
| Vue Richtung | 12 o'clock |
| Äntwert Zäit | 50 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/50/50 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K 50% NTSC |
| Liichtquell | WLED , 20K hours , With LED Driver |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
