| Part Number | AM-480272HBTMQW-T00H |
| Mark | AMPIRE |
| Gréisst | 4.3 |
| Applikatioun | Industrial |
| Opléisung | 480×272 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 250:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S1P WLED , 20K hours , No Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | AMPIRE |
| Modell Numm | AM-480272HBTMQW-T00H |
| Écran Gréisst | 4.3 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×272 (WQVGA) 128PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 95.04 × 53.856 (H×V) |
| Kontur (mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| Bezel Beräich (mm) | 98.7 × 57.5 (H×V) |
| Behandlung | - |
| luminance | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 250 : 1 (Typ.) (TM) |
| Vue Wénkel | 65/65/45/45 (Typ.)(CR≥10) |
| Äntwert | 40 (Typ.)(Tr+Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M |
| mass | - |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | PCAP |
| Signal Typ | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
