| Part Number | AM-1024768TTMQW-T00H |
| Mark | AMPIRE |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AMPIRE |
| Modell | AM-1024768TTMQW-T00H |
| diagonal Gréisst | 10.4 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 123PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 211.2(H)×158.4(V) mm |
| kontur dim. | 236(H)×176.9(V) ×7.9(D) mm |
| bezel Beräich | 214.8(H)×162.0(V) mm |
| Behandlung | Antiglare |
| luminance | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 75/75/75/75 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M |
| Liichtquell | WLED [4 strings] , 30K hours , With LED Driver |
| Gewiicht | 290g (Max.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | 4-wire Resistive Touch |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
