| Part Number | AM-1024768R3TNQW-T00H |
| Mark | AMPIRE |
| Gréisst | 12.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | AMPIRE |
| Modell | AM-1024768R3TNQW-T00H |
| diagonal Gréisst | 12.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 105PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 245.76(H)×184.32(V) mm |
| kontur dim. | 279(H)×209(V) ×11.2(D) mm |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M |
| Liichtquell | WLED , 30K hours , With LED Driver |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
