| Part Number | AM-1024768FCTMQW-T00H |
| Mark | AMPIRE |
| Gréisst | 10.4 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AMPIRE |
| Modell | AM-1024768FCTMQW-T00H |
| diagonal Gréisst | 10.4 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 123PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 210.4(H)×157.8(V) mm |
| kontur dim. | 238.6(H)×175.8(V) mm |
| luminance | 280 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 14/11 (Typ.)(Tr/Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Betribssystemer Modus | Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.2M 57% NTSC |
| Liichtquell | WLED , 30K hours , With LED Driver |
| Gewiicht | - |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
