| Part Number | AM-1024600K7TMQW-T53H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | 5S3P |
| Interface | LVDS |
| Panel Mark | AMPIRE |
| Panel Gréisst | 7.0" |
| Resolutioun | 1024(RGB)×600, WSVGA, 169PPI |
| Affichage Beräich | 153.6(W)×90(H) mm |
| Kontur Gréisst | 165.5(W)×104.44(H) ×11.93(D) mm |
| Hellegkeet | 425 cd/m² (Typ.) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| beschte Vue op | 6 o'clock |
| weisen Faarwen | 262K/16.7M |
| Frequenz | 60Hz |
| Panel Gewiicht | TBD |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Modell | AM-1024600K7TMQW-T53H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 20/20 (Typ.)(Tr/Td) |
| Lampe Typ | 5S3P WLED , 50K hours , With LED Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
