| Part Number | ACX425AKM |
| Mark | SONY |
| Gréisst | 3.7 |
| Applikatioun | MPH |
| Opléisung | 480×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 320 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | SONY |
| Panel Modell | ACX425AKM |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 3.7 inch |
| Resolutioun | 480(RGB)×800 , WVGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 48.24×80.4 mm |
| skizzéieren | 53.9×90 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 320 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193190% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| Input Volt | 2.6/2.6V (Typ.)(VDD/AVDD) |
| Applikatioun | MPH |
