| Part Number | A035QN05 V1 |
| Mark | AUO |
| Gréisst | 3.5 |
| Applikatioun | PP |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Serial RGB |
| Panel Mark | AUO |
| Panel Modell | A035QN05 V1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 70.32×52.74 mm |
| skizzéieren | 76.9×63.9×3.12 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193145% |
| Äntwert Zäit | 10/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6S1PWLEDWithout Driver |
| Signal Interface | Serial RGB (8-bit) + SPI, 50 pins |
| Input Volt | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Applikatioun | PP |
