| Part Number | A025DL02 V5 |
| Mark | AUO |
| Gréisst | 2.5 |
| Applikatioun | DSC |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Serial RGB |
| Panel Mark | AUO |
| Panel Modell | A025DL02 V5 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 2.5 inch |
| Resolutioun | 320(RGB)×240 , QVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 50.4×37.8 mm |
| skizzéieren | 60.73×45.07 mm |
| Uewerfläch | Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Min.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 15/20 (Typ.)(Tr/Td) |
| Vue Wénkel | 55/55/45/70 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 3S1PWLED |
| Signal Interface | Serial RGB (8-bit) + SPI, CCIR656, 39 pins |
| Input Volt | 3.3/3.3 (Typ.)(VDC/VDCI) |
| rohs: | |
